|Main Power:||15 Kw||Hydraulic Power:||7.5Kw|
|Material:||Galvanized Steel Coil||Thickness :||1.0~3.0mm|
|Roller station:||18 Stations||Speed:||16~20m/min|
|Size:||Approx. 10m*1.5m*1.8m||Weight:||10 Tons|
CZ Purlin Roll Forming Machine Durable,
CZ Purlin Roll Forming Machine 3.0mm,
CZ Purlin Roll Former High Efficiency
High Quality Durable And Stable Fully Automatic CZ Purlin Roll Forming Machine
1. Description of CZ purlin roll forming machine
The fully automatic CZ steel integrated machine is also called C/Z interchangeable roll forming machine. It is a high-automatic purlin forming equipment controlled by a PLC computer, which can realize the interchangeable production of C/Z two types and various specifications of purlins in a short time. In the production process, the computer is automatically controlled, and there is no need to replace the forming roller when changing specifications, which changes the history of using C and Z to process two different types of purlins, saving a lot of investment cost and site space for users.
Advantages of CZ Interchangeable Purlin Roll Forming Machine:
1). The produced C-type purlins have good straightness and good compression and bending resistance;
2). The produced Z-type purlins can be installed in reverse lap to increase the installation strength of the connection points;
3). The electrical automatic control system is equipped with an error-reporting device to ensure the safety and stability of the production line;
4). The transmission adopts a deceleration motor plus frequency conversion control, speed control, accurate and reliable length positioning;
5). Two different configuration files of CZ can be rolled, saving the user's purchase cost and floor space;
6). The conversion of the two profiles can be realized without changing the forming roller, with high speed and high efficiency.
In addition to CZ Interchangeable Purlin Roll Forming Machines, Lebron-Machinery also provides C-type purlin machines and Z-type purlin machines for users who have individual user requirements. These two kinds of purlin roll-forming machines are machines independently developed by Lebron-Machinery at the beginning of its establishment. After 20 years of technological upgrading and improvement, the technology is mature and the products are excellent. The company also has other main products. Please feel free to inquire if necessary.
2. Technical Parameters of CZ Purlin Roll Forming Machine
|1||Suitable Material||GI, GL, PPGI, PPGL Coil, Q235 Coil|
|3||Roller Station||16 stations|
|4||Forming Speed||8~12m/min (including the punching and cutting)|
|5||Roller Material||GCr15 Bearing Steel. Quenched. Hardness: 58~62 HRC|
|6||Main Motor Power||15 KW|
|7||Shaft Material||Cr40 steel, Tempering, and Quenching|
|10||Blade Material||C12MoV, Quenched|
|11||Hydraulic Station Power||7.5 KW|
|12||Drive Type||Single row Chain Drive|
|13||Machine Size||10500mmx900mmx1500mm (L*W*H)|
|14||Machine Weight||Approx 8 tons|
|15||Machine Frame||48mm Thick Plate|
|16||PLC Control System||Panasonic|
|20||Other Electrical Components||Schneider|
3. Main components of CZ Purlin Roll Forming Machine
|1||5Tmanual decoiler||1||As one complete part|
|10||Spare parts and tools||1||As attaching list|
1). Factory directly-sell price. This will surely save you costs.
2). From buying to installation to use, we have professional teams to help you. We can save your time, and make your operation easier.
3). Long-time Warranty. 18 months warranty. During this period, all the accessories are free. If the machinery has a nonrepairable quality problem, we accept the replacement or return.
4). Rich experience in Logistics and Shipping. We can not only guarantee the machine’s safe and fullness during transportation but also save lots of unnecessary costs for you.
1. Q: Are you a manufacturer?
A: Yes, we are a manufacturer with over 11 years of experience.
2. Q: If I am new in this field. How could I understand the machine very well?
A: We have a very professional sales team and technology team. We will provide you the detailed introductions by photos, videos, and technical proposals. If you have any questions, we can reply to you in the shortest time.
3. Q: I have no Whatsapp or Skype, how could I contact with you
A: Send one email to me (email@example.com). Leave your contact information for me. I will contact you. It is free.
4. Q: How should I do if I would like to order my machine
A: Send us your design drawing if you have any. Or tell us your design idea. we arrange for our engineers to make the drawing for your confirmation first. After every technical detail is confirmed, meantime, we reach an agreement on the price, delivery time, after-sales service, etc. We can sign a contract then
5. Q: Can you use other brands of spare parts for me if I want?
A: Yes. We can.
