Material: | No.45 Steel. Chromed, Quenching | Roller Station:: | 18 Stations |
---|---|---|---|
Controller:: | PLC System | Forming Speed: | 8-12m/min |
Thickness:: | 0.8~2.0mm | Warranty Period:: | 18 Months |
High Light: | cable tray manufacturing machine,cable tray punching machine |
Speed 8-12m/min Cable Tray Roll Forming Machine Hydraulic Cut PLC Control
1. Technical parameter
Items | Specifications | |
Material of coil | Material Width | 200-950mm |
Material Thickness | 0.8-2.0mm | |
Uncoiler | 6 tons manual | |
Forming system | Rolling Speed | 2-4m/min |
Roller Stations | 24 stations | |
Roller Material | GCr15 quench treatment | |
Shaft DIA | D65mm | |
Main Motor Power | 22kw | |
Cutting system | Material Of Cutting | Cr15 with quench treatment |
Hydraulic cutting Power | 5kw | |
Electrical control system |
Electric Source | 380V, 50HZ,3 phase |
Control System |
PLC (Panasonic) |
2. Technological process
Uncoiler—Feeding—Leveling—Punching & Cutting—Roll forming—Output table
3. After-sales service
Technical Support
Fully providing technology supports both within and after the warranty period. Feed back to our customers at the first time.
Spare Parts
Promptly providing spare parts and wearing parts.
Upgrade
Improve technology and upgrade of equipments.
4. FAQ
1)Q: What is the Warranty Machine ?
A: For our roll forming machine , we have 1 year warranty. If any quality problems in this period ,we will take on the shipping cost and replacement.
2)Q: Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available across the world. We
need your machines running in order to keep your business running.
3) Q: How do your machines compare with other big companies in this market?
A: We are up to date with the latest technology and improve our machines accordingly
4)Q: How does your factory do regarding quality control?
A: Quality is priority. We always attach great importance to quality control from the very
beginning to the end of the production. Every product will be fully assembled and carefully tested before it's packed for shipment.
5) Q: Do you sell only standard machines?
A: No, most of our machines are built according to customers specifications, using top brand name components.
Main Components of Cable Tray Roll Forming Machine
5. Machine Components
No. | Item | Quantity |
1 | Uncoiler | 1 Set |
2 | Servo Feeder | 1 Set |
3 | Hydraulic Punching Device | 1 Set |
4 | Cable Tray Roll Former | 1 Set |
5 | Hydraulic Cutting | 1 Set |
6 | Hydraulic Station | 1 Set |
7 | Ran-out Table | 2 Sets |
8 | PLC Control System Cabinet | 1 Set |
6. Layout of Cable Tray Roll Forming Machine
