High Efficiency Double Layer Roll Forming Machine 20 Stations Fully Automatic

High Efficiency Double Layer Roll Forming Machine 20 Stations Fully Automatic
High Efficiency Double Layer Roll Forming Machine 20 Stations Fully Automatic

Large Image :  High Efficiency Double Layer Roll Forming Machine 20 Stations Fully Automatic

Product Details:
Place of Origin: Jiangsu, China
Brand Name: Lebron-Machinery
Certification: ISO CE
Model Number: Corrugated and Trapezoidal Double Layer
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: USD 15000-25000 per Set
Packaging Details: Standard export packing with each machine tied and protected in the container
Delivery Time: 35 Workdays
Payment Terms: L/C, T/T
Supply Ability: 25 Sets per Month
Detailed Product Description
Main Power: 7.5Kw Machine Size: 8.0*1.8*2.0m
Machine Weight: About 10 Tons Roller Station: 20 Stations (upper) & 22 Stations (downer)
Hydraulic Power: 4.0KW Speed: 12~15m/min
High Light:

Fully Automatic Double Layer Roll Former

,

20Stations Double Layer Roll Former

,

4.0KW Double Roll Former machine

Easy Operation High Efficiency Double Layer Roll Forming Machine Fully Automatic




1. Description of Double Layer Roll Forming Machine



Compared to a single layer roof panel roll forming machine, this double layer roll forming machine is designed to produce two different kinds of metal sheets which can be one trapezoidal roofing and one metal roof tile



It shall be pointed out that the two layers of roll forming parts on this double layer roll forming machine cannot work at the same time, which means each one of the roll forming systems (top roll forming and bottom roll forming) will stop when the other is working.



The double-layer roll forming machine combines the two models very well, with reasonable structure and a beautiful appearance. It has the characteristics of saving space and simple operation and is especially suitable for customers with small sites and on-site construction.



We have excellent after-sales service and can be specially designed and manufactured according to user requirements. At the same time, it provides guidance to users, production, installation, debugging, and maintenance.







2. Technical Parameters



No. Item Description
1 Suitable Material GI, PPGI, GL, PPGL Steel Coil
2 Roller

Upper layer: 13 Rows

Downer Layer: 15Rows

3 Dimensions 8*1.8*2m
4 Main Power 7.5Kw
5 Hydraulic Station Motor 4Kw
6 The thickness of the plate 0.3-0.8mm
7 Productivity 10-15m/min
8 Material of the cutting blade Cr12, Quenched treatment 58℃-60℃
9 Diameter of the roller Φ70mm
10 Weight About 5200kgs
11 The main structure of the machine 350H beams
12 Processing precision Within 1.0mm
13 The side panel of the machine 16mm
14 Chain Wheel and Cycle Chain 1.5 Inch
15 Voltage 380V 50Hz 3phases or as customers need
16 Control system PLC control (Siemens)
17 Frequency system Siemens
18 Drive mode Motor + Chain
20 Rolling materials 45# forging steel with chromium plate



3. Main Components

Name Quantity
Uncoiler 1 set
Coil sheet guiding device 1 set
Main roll forming system 1 set
Cutting device 1 set
Hydraulic station 1 set
PLC control system 1 set
Support table 2 sets
While in some other cases, we can provide hydraulic decoiler and auto stacker as per request.




4. Our Advantages



1). We can make and design all kinds of roll forming machines according to customers’ requests.

2). This is very perfect and durable equipment. We have more than 11 years of experience.

3). This kind of machine has the best quality and the best price.

4). Our product has been exported to many regions and won a high reputation because of the high quality and reasonable price.







5. FAQ:


1Q: Are you a factory or trading company?

1A: We are a factory.



2Q: Where is your factory located?

2A: Our factory is located in Wuxi City, Jiangsu Province, China. You are warmly welcome to visit us!



3Q: What should I provide if I would love to customize the machine?

3A: We need profile drawing, material information, such as feeding width, thickness, yield strength of steel coil, voltage and your special requirements.



4Q: What I should do if I just start to know roll forming machinery?

4A: Contact us immediately, we provide free consultant pre-sales service.



5Q: Can you make the machine according to my design or phototype?

5A: Yes. We have a professional designer for working out the most suitable design and production plan for the machine that you are going to book with us



6Q: How can I trust you that machines pasted testing running before shipping?

6A: We record the testing video for your reference. You are welcome to visit us and test the machine in our factory.



7Q: Do you provide installing and training overseas?

7A: Overseas machine installation and worker training services are optional.



8Q: How is your after-sales support?

8A: We provide technical support online as well as overseas services by skillful technicians.



9Q: Guarantee period:

9A: Within one year since the date of finishing commissioning. The guarantee covers all the electric, mechanic, and hydraulic parts in the line except for the easy-worn parts.
