Stainless Steel 304 Precision Machining Vacuum Suction Press Roller 1300mm

Stainless Steel 304 Precision Machining Vacuum Suction Press Roller 1300mm
Stainless Steel 304 Precision Machining Vacuum Suction Press Roller 1300mm Stainless Steel 304 Precision Machining Vacuum Suction Press Roller 1300mm Stainless Steel 304 Precision Machining Vacuum Suction Press Roller 1300mm Stainless Steel 304 Precision Machining Vacuum Suction Press Roller 1300mm

Large Image :  Stainless Steel 304 Precision Machining Vacuum Suction Press Roller 1300mm

Product Details:
Place of Origin: Wuxi City, Jiangsu, China
Brand Name: Lebron-Machinery
Certification: ISO 9001: 2008
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: USD40000~150000 per Piece
Packaging Details: Standard Export Packing with each bundle tied and protected in the container
Delivery Time: 30 Days
Payment Terms: L/C, T/T
Supply Ability: 1 Set per Month
Detailed Product Description
Application: Paper Industry Shell Material: Stainless Steel 304, 316
Shaft Head Material: QT500-7 Vacuum Chamber: SS304
Surface Covering: Rubber With Drilled Hole Rubber Thickness: 20-25mm
High Light:

Vacuum Suction Press Roller

,

Stainless Steel 304 Vacuum Press Roller

,

1300mm Vacuum Suction Press Roller

Paper Machine Use High Quality Precision Machining Vacuum Suction Press Roller





1. Description of Vacuum Suction Press Roller



When it comes to the paper industry, you require performance and reliability that you never need to question. To meet that need, suction and vacuum rolls are manufactured, and serviced.



We can provide documented inspection of all critical fits including bearing diameters, housing bores, the body bore, seal surfaces, drive diameters, Head fits, Suction boxes, Seal Strips, bore profile, body profile, and surface finishes.



Vacuum Suction Press Roll

Manufacturing Standard

Shell in 304, 316, DSS (SAF 2304(Cr23), SAF2205(Cr22)

Vacuum box welded by stainless steel

Air bellows & sealing strips provided by LERIPA or AISA Paper Tech

Cast iron bearing houses

Grease lubrication



Optional

Stainless Steel bearing housing

Oil lubrication

Rubber or PU covered

Through-hole or Blind hole drilled or Grooved

Rubber service provided by STONEWOOD WARD



Supply limits

Diameter: 500-1300mm

Face length: 10000mm

Working Speed: max up to 2000m/min

Balancing: Rotor Rigid or flexible rotor









2. Technical Parameters



No.

Trim Width

(mm)

Bearing Center Distance

(mm)

Diameter*Face Length

(mm)

Width Adjustment Range (mm) Suction Port Form Rubber Thickness (mm)
1 1575 2400 Φ650×2020 1785~1565 Single 25
2 1600 2600 Φ700×2080 1810~1570 Multiple 25
3 1760 2760 Φ600×2260 1980~1780 Single 25
4 1760 2800 Φ700×2280 2010~1760 Multiple 25
5 1760 2880 Φ750×2290 2030~1730 Single 25
6 1880 2900 Φ700×2380 2120~1820 Multiple 25
7 2362 3300 Φ700×2780 2400~2500 Multiple 25
8 2362 3400 Φ750×2900 2630~2400 Multiple 25
9 2400 3620 Φ750×3000 2730~2430 Multiple 25
10 2640 3700 Φ750×3200 2910~2610 Multiple 25
11 2800 4000 Φ750×3400 3110~2810 Multiple 25
12 3150 4300 Φ750×3710 3430~3130 Single 25
13 3200 4300 Φ750×3760 3480~3180 Multiple 25
14 3300 4350 Φ750×3800 3510~3310 Multiple 25
15 3500 4600 Φ800×4100 3810~3510 Single 25
16 3600 4850 Φ800×4300 4010~3610 Multiple 25
17 3800 5110 Φ850×4450 4150~3850 Single 25
18 4200 5460 Φ850×4800 4510~4210   25
19 4400 5810 Φ850×5150 4860~4460 Single 25
20 4500 5900 Φ1000×5230 4950~4550 Single 20
21 4800 6300 Φ1000×5630 5350~4950 Single 20
22 5000 6500 Φ1000×5750 5470~5170 Single
23 5500 7000 Φ1000×6250 5970~5670 Single
24 5800 7350 Φ1200×6550 6270~5970 Single





3. FAQ


1Q: Are you a factory or trading company?

1A: We are a factory.



2Q: Where is your factory located?

2A: Our factory is located in Wuxi City, Jiangsu Province, China. You are warmly welcome to visit us!



3Q: What should I provide if I would love to customize the machine?

3A: We need profile drawing, and material information, such as feeding width, thickness, yield strength of steel coil, voltage and your special requirements.



4Q: What I should do if I just start to know roll forming machinery?

4A: Contact us immediately, we provide free consultant pre-sales service.



5Q: Can you make the machine according to my design or phototype?

5A: Yes. We have a professional designer for working out the most suitable design and production plan for the machine that you are going to book with us



6Q: How can I trust you that machines pasted testing running before shipping?

6A: We record the testing video for your reference. You are welcome to visit us and test the machine in our factory.



7Q: Do you provide installing and training overseas?

7A: Overseas machine installation and worker training services are optional.



8Q: How is your after-sales support?

8A: We provide technical support online as well as overseas services by skillful technicians.



9Q: Guarantee period:

9A: Within one year since the date of finishing commissioning. The guarantee covers all the electric, mechanic and hydraulic parts in the line except for the easy-worn parts.





4. Product Picture



Stainless Steel 304 Precision Machining Vacuum Suction Press Roller 1300mm 0





Stainless Steel 304 Precision Machining Vacuum Suction Press Roller 1300mm 1





Stainless Steel 304 Precision Machining Vacuum Suction Press Roller 1300mm 2











5. Work Place:



Stainless Steel 304 Precision Machining Vacuum Suction Press Roller 1300mm 3





6. Package



Stainless Steel 304 Precision Machining Vacuum Suction Press Roller 1300mm 4
