Stable Long Service Shutter Door Roll Forming Machine Shutter Door Slat Machine

Stable Long Service Shutter Door Roll Forming Machine Shutter Door Slat Machine
Stable Long Service Shutter Door Roll Forming Machine Shutter Door Slat Machine Stable Long Service Shutter Door Roll Forming Machine Shutter Door Slat Machine Stable Long Service Shutter Door Roll Forming Machine Shutter Door Slat Machine Stable Long Service Shutter Door Roll Forming Machine Shutter Door Slat Machine

Large Image :  Stable Long Service Shutter Door Roll Forming Machine Shutter Door Slat Machine

Product Details:
Place of Origin: China
Brand Name: Lebron-Machinery
Certification: ISO/CE/CSA/Soncap
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD10000~20000 Per Set
Packaging Details: Standard export packing with each machine fixed and protected in the container
Delivery Time: 30 days
Payment Terms: L/C, T/T
Supply Ability: 30 Sets per Month
Detailed Product Description
Main Power: 5.5KW Hydraulic Power: 3KW
Suitale Thcikness: 0.8-1.2mm Roller Station: 14 Stations
Speed: 12~15m/min Weight: About 4.6Tons
High Light:

automatic roller shutter machine

,

roller shutter door making machine

,

Shutter Door Slat Machine

Stable and Long Service Shutter Door Roll Forming Machine Shutter Door Slat Machine



1. Description of shutter door roll forming machine:



Our Shutter Door Slat Roll Forming Machine is customized, we can design and produce a rolling shutter door slat roll forming machine according to your outline drawing. Here I am attaching a profile drawing of our rolling door for your reference, you can choose what you want and then tell me, we will produce the machine according to the profile drawing you choose.



For the rolling door manufacturing machine, it has many parts:
1. Unwind the coil.
2. Feed the material to the punching machine (it is possible to make the shutter sliding cover have holes).
3. Roll forming parts, for our machine, the forming speed is 0-30m/min, adjustable. Usually, we will manufacture a shutter door forming machine with a gear drive, which will make the machine have strong moving power.
4. Punch. This part will be used with the cutting blade. When cutting, the machine will punch holes together.
5. Cutting part. We have two cutters for you to choose from, one is a flying saw and the other is a hydraulic cutter.





2. Technical details of shutter door roll forming machine:



No. Item Description
1. Suitable material Color steel sheet, galvanized steel sheet, aluminum sheet
2. Installation Dimension 12000X1700X1500 (L*W*H)
3. Main motor power 5.5KW with Cycloidal reducer
4. Hydraulic station power 3KW
5. Hydraulic oil pump 40#
6. Thickness of material 0.8mm~1.2mm
7. Diameter of Shaft Φ70mm
8. Material expands width 760mm
9. Electric tension 380V 3phase 50HZ or as the customer's requirements
10. Material of roller High grade 45# forged steel plated with hard chrome plating
11. Controlling system PLC
12. Processing speed 8-12m/min(glazed tile is 2-3m/min)
13. Processing precision within 1.00mm (depending on design)
14. Material of cutting blade Cr12 mold steel with quenched treatment
15. Kind of drive 1.0 inch chain
16. Roller station 14 Rollers
17. Roller material high grade 45#steel; Cr12 quenching
18. Leak frame load-bearing 4.6T





3. Main components of shutter door roll forming machine





Decoiler 1 Set
Feeding Device 1 Set
Roll Forming Unit  1 Set
Post Cutting Unit 1 Set
Hydraulic Station  1 Set
Electric Control Cabinet 1 Set
Receiving Table 1 Set





4. FAQ:



1Q: Are you a factory or trading company?

1A: We are a factory.



2Q: Where is your factory located?

2A: Our factory is located in Wuxi City, Jiangsu Province, China. You are warmly welcome to visit us!



3Q: What should I provide if I would love to customize the machine?

3A: We need profile drawing, material information, such as feeding width, thickness, yield strength of steel coil, voltage, and your special requirements.



4Q: What I should do if I just start to know roll forming machinery?

4A: Contact us immediately, we provide free consultant pre-sales service.



5Q: Can you make the machine according to my design or phototype?

5A: Yes. We have a professional designer for working out the most suitable design and production plan for the machine that you are going to book with us



6Q: How can I trust you that machines pasted testing running before shipping?

6A: We record the testing video for your reference. You are welcome to visit us and test the machine in our factory.



7Q: Do you provide installing and training overseas?

7A: Overseas machine installation and worker training services are optional.



8Q: How is your after-sales support?

8A: We provide technical support online as well as overseas services by skillful technicians.



9Q: Guarantee period:

9A: Within one year since the date of finishing commissioning. The guarantee covers all the electric, mechanic, and hydraulic parts in the line except for the easy-worn parts.





Stable Long Service Shutter Door Roll Forming Machine Shutter Door Slat Machine 0





Stable Long Service Shutter Door Roll Forming Machine Shutter Door Slat Machine 1





Stable Long Service Shutter Door Roll Forming Machine Shutter Door Slat Machine 2
