Product Details:
Payment & Shipping Terms:
|
Machine Size: | About 7.5m*1.2m*1.0m | Suitable Material: | Galvanized Steel Coil |
---|---|---|---|
Thickness: | 0.8-1.2mm | Speed: | 20-25m/min |
Roller: | 45# Steel, Coated With Hard Chrome | Roller Station: | 18 Stations |
High Light: | 18 Stations steel door frame making machine,0.8mm steel door frame making machine,0.8mm metal door forming machine |
High Stability High Durable High-Efficiency Door Frame Roll Forming Machine
1. Description of Door Frame Roll Forming Machine
The Door Frame Roll Forming Machines can be divided into three categories: ordinary door frame forming machines (one-time), door frame half forming machines (adjustable), and fully automatic door frame forming machines.
Door frame semi-forming machine (adjustable) Purpose: anti-theft door or indoor and outdoor door frames. Can be designed and manufactured according to customer requirements.
Compared with the traditional clay brick machine, the door roll frame forming machine can choose industrial waste residues: coal ash, coal gangue, and various tailings as the main raw materials. The door frame roll forming machine adopts the platform mold to vibrate hydraulic pressure forming, the forming cycle is short, and the production efficiency is high.
The use of door frame roll forming machines is more environmentally friendly, more energy-saving, and waste recycling. The door frame roll forming machine uses three bars to press up and down to form at one time, without a brick supporting board.
Process flow of door frame forming machine:
Uncoiling -- leveling&feeding -- continuous punching -- roll forming -- fixed-length cutting--receiving
2. Technical Parameters of Door Frame Roll Forming Machine
Weight | About 8000kgs |
Size | About 7.5m*1.2m*1.0m (L x W x H) |
Suitable Material | Galvanized steel strip |
Thickness | 0.8~1.2mm |
Coil width | 240mm |
Yield strength | 235Mpa |
Rollers station | 18 Stations |
Roller Shaft Diameter | 75 mm |
Roll Forming Speed | 20-25m/min |
Production Speed | Approx.15m/min |
Roller Material | 45# steel, coated with chrome, quenched |
Cutter material | Cr12 mold steel, with quenched treatment |
Controlling system | PLC and Converter |
Electric power requirement | Main power: 7.5 KW |
Hydraulic power: 4 KW | |
Electric voltage | 380V 50Hz 3 Phase (as per local requirement) |
3. Our Advantages
1). We are a factory with over 10 years experience in manufacturing Roll Forming Machines;
2). We have our own powerful research and development team
3). We have more than 15 technicians.
4). 5 engineers with more than 20 years of experience
5). We have an advanced Laser Cutting Machine, CNC Machining Center, Polishing Line, Painting Line, etc. These advanced production equipment guarantee that the good quality of each part and the appearance of our machines;
6). Our machines have reached the International Inspection Standards;
4. FAQ
1). Q: Are you a manufacturer, trading company?
A: We are a manufacturer, and we have built up our company since 2007.
2). Q: Where is your factory located?
A: Our factory address is: No. 551, the Zhenze West Road, Huazhuang Street, Binhu District, Wuxi City, Jiangsu, China
3). Q: How can I get to your factory?
A: Our factory is near Shanghai Airport, we can pick you up at the airport. Or you can by plane direct to Wuxi airport. We can pick you up.
4). Q: If I will need to stay in your place for a few days, is that possible to book the hotel for me?
A: It’s always my pleasure, a hotel booking service is available.
