Product Details:
|
Weight: | About 3500 Kgs | Size: | About 6.00mX0.70mX0.90m (Length*Width*Height) |
---|---|---|---|
Roller Stations: | 12-14 Stations | Diameter Of Forming Rollers Shafts: | 60mm |
Roll Forming Speed: | 15-20m/min | Forming Rollers Material: | No.45 Steel, Coated With Chromed Treatment |
Controlling System: | PLC And Converter | Main Motor Power: | 5 Kw |
Installation: | Technicians Can Go To Your Place To Make The Installation | Warranty Period: | 18 Months |
Highlight: | automatic rolling shutter machine,rolling shutter slats roll forming machine |
Easy Control High Hydraulic Cut Type Door Shutter Roll Forming Machine Full Automatic
1. Description of door shutter roll forming machine:
For the rolling shutter strip making machine, it is a machine will make shutter door slats, Our machine can do thickness for 0.3-1.4mm, the shape will be design by your demand.
LBM is manufacturing high quality guardrail roll forming machines, and regularly exported to Turkey, Indonesia, Philippines, Malaysia, India, Angola, etc.
2. Technical details of door shutter roll forming machine:
Machine Specifications | |
Weight | About 3500kgs |
Size | About 6.00mX0.70mX0.90m(length x width x height) |
Color | Main color: blue |
Warning color: yellow | |
Suitable Raw Material | |
Material | Galvanized Steel Coils |
Thickness | 0.3-0.6mm |
Yield Strength | 235Mpa |
Main Technical Parameters | |
Quantity of forming rollers stations | 12-14 |
Diameter of forming rollers shafts | 60mm |
Roll Forming Speed | 15-20m/min |
Forming rollers material | No.45 steel, coated with chromed treatment |
Cutter material | CR12 mould steel, with quenched treatment |
Controlling system | PLC and Converter |
Electric Power requirement | Main motor power: 3kw |
Hydraulic unit motor power: 3kw | |
Electric voltage | According to customer’s requirement |
3. Main components of door shutter roll forming machine
Decoiler / Uncoiler | 1 Unit |
Feeding Guide | 1 Unit |
Main Roll Forming Machine | 1 Unit |
Heating Device | 1 Unit |
PU Injection Foaming Machine | 1 Unit |
Pneumatic Tracking Punching | 1 Unit |
Servo Flying-saw Cutting | 1 Unit |
PLC Electrical Control Board | 1 Unit |
Run out Support Table | 1 Unit |
4. Production Flows:
Uncoiling the sheet---Infeed guiding--Roll forming---Rectifying the straightness---Measure length---Cutting the panel--panels to the supporter (option: automatic stacker)
5. Advantages:
· Germany COPRA software design
· 5 engineers with more than 20 years experience
· 30 professional technician
· 22 sets advanced CNC production lines on site
· Passionate Team
· Installation engineers can reach your factory within 6 days
· 3 years maintenance and whole life technical support
6. PLC Control System
1. Adopts PLC control technology, frequency adjust speed technology, realize the automatic production.
2. Provide good man and machine screen, which can set the batches, plate length, and quantity.
3. Operation type: Touching screen + Button
4. Using encoder to calculate the number and measuring the length
7. Application:
This machine is widely used in the production of the door shutters.
